LANSIS 261

The LANSIS 261 features an exclusive implementation of a back‑illuminated, deep‑depletion CCD sensor with a 2048 × 263 pixel format, designed specifically for demanding spectroscopy applications. The combination of deep‑depletion technology, high‑speed readout, and low noise performance makes the LANSIS 261 particularly well suited for near‑infrared (NIR) and Raman spectroscopy, where high sensitivity and signal integrity are essential.

By delivering high quantum efficiency across a broad spectral range and supporting deep cooling, the LANSIS 261 provides reliable performance for OEM and system‑integrated spectroscopic instruments.

Category: Princeton Instruments Tag: Scientific Cameras Brand: Princeton Instruments

Description

LANSIS – CCD Cameras for Spectroscopy

The LANSIS™ CCD camera family from Teledyne Princeton Instruments represents the latest generation of CCD array detector technology, specifically developed for OEMs and system integrators in spectroscopy applications. LANSIS cameras combine high reliability, strong performance, and cost efficiency to meet a wide range of technical and budget requirements.

Designed for demanding spectroscopic techniques such as Raman spectroscopy, optical emission spectroscopy (OES), fluorescence, and photoluminescence (PL), LANSIS cameras deliver high sensitivity across the ultraviolet to near-infrared wavelength range. The use of back-illuminated CCD sensors, with optional eXcelon® technology, provides high quantum efficiency while minimizing etaloning effects, particularly in the near-infrared.

LANSIS cameras are engineered for easy system integration, offering multiple mechanical mounting options and a plug-and-play user experience. Full compatibility with Teledyne’s PICam™ software development kit enables straightforward integration with common development environments such as Python, C++, and LabVIEW.

High manufacturing consistency and permanent vacuum-sealed technology ensure long-term stability and reliability in OEM instrumentation. With multiple sensor formats available, the LANSIS platform supports a broad range of spectroscopy system designs for both scientific and industrial applications.

LANSIS 261 CCD Camera

Key Specifications

Sensor format: 2048 × 263 array with 15 µm pixels
Cooling: Liquid cooled down to −75 °C
Sensitivity: Up to 95% peak quantum efficiency with back‑illuminated CCD technology

Specifications

Resolution	2048 × 263
Megapixels	0.5
Sensor Model	Back-illuminated AIMO CCD sensor, Grade 1
Pixel Size	15 µm
Sensor Type	CCD
Spectral Range	200–1100 nm
Color / Mono	Mono
Lens Mount	Spectroscopy mount
Data Interface	USB 3.0

Features

Triggering Modes	Start on single trigger, readout per trigger, exposure during trigger pulse

Performance

Dark Current	0.02 e⁻/pixel/second @ −65 °C
Dynamic Range	14,000 : 1
Full Well Capacity (Qsat)	70,000 e⁻ (typical, low gain)
Quantum Efficiency (Mono)	95%
Read Noise	5.0 e⁻
Sensor Material	Silicon

Physical

Cooling	−65 °C (TEC air cooled); −75 °C (liquid cooled)
Digitization (ADC)	16-bit
Dimensions (W × H × L)	151 × 123.5 × 123.5 mm
Field of View	30.72 × 3.96 mm
Mass	3.05 kg (6.72 lbs)
Operating Humidity	0–80% (non-condensing)
Operating Temperature	5 °C to 30 °C (non-condensing)
Storage Humidity	0–90% (non-condensing)
Storage Temperature	−20 °C to 60 °C

Recommended System Configuration

Accessories (Included)	Power supply and cables, MCX to BNC cables (×3), USB 3.2 interface cable, data acquisition software, certificate of performance

Compliance & Certifications

Certifications	FCC Part 15 Subpart B (Class A), CE, UKCA, RoHS 3, PSE, ISO 9001:2015
Warranty	1 year, permanent vacuum guarantee

LANSIS Camera Comparison

Model	LANSIS 261	LANSIS 424	LANSIS 471
Sensor Format	2048 × 263	2048 × 2048	1024 × 1024
Megapixels	0.5 MP	4.2 MP	1.05 MP
Pixel Size	15 µm	13.5 µm	13 µm
Sensor Type	Back-illuminated AIMO CCD	Back-illuminated AIMO CCD	Back-illuminated AIMO CCD
Spectral Range	200–1100 nm	200–1100 nm	200–1100 nm
Peak Quantum Efficiency	95%	95%	95%
Dark Current	0.02 e⁻/pixel/s @ −65 °C	0.008 e⁻/pixel/s @ −90 °C	0.001 e⁻/pixel/s @ −90 °C
Read Noise	5.0 e⁻	≤ 4.0 e⁻	≤ 4.0 e⁻
Full Well Capacity	70,000 e⁻	100,000 e⁻	100,000 e⁻
Cooling	−65 °C (air) / −75 °C (liquid)	−90 °C (liquid)	−90 °C (liquid)
Field of View	30.72 × 3.96 mm	27.6 × 27.6 mm	13.3 × 13.3 mm
Lens / Spectroscopy Mount	Spectroscopy mount	F‑mount (others optional)	C‑mount (others optional)
Interface	USB 3.0	USB 3.0	USB 3.0
Typical Applications	Spectroscopy, Raman, OES	Low‑light imaging, fluorescence, in‑vivo	Low‑light imaging, luminescence
