Nibble R 2.0
Description
Spectral sensing module, including
- Hyperspectral Sensor ChipSense x
- Electronics
- Light source and optics
Standard* available in various configurations to be specified at product ordering:
- Wavelength range configuration: VIS, NIR, SWIR, VIS-NIR-SWIR
- Mechanical set-up: Complete, Without Housing, PCB-Only
Compatible with SpectraByte (Desktop app) and SpectraWeb (Browser app)
Specifications
| Parameter Unit Specifications | ||
| Intended use/application | Solid Materials or Liquids
Analysis |
|
| Certifications | CE/FCC | |
| Optical Sensing Mode | Reflection | |
| Product Assembly Configurations | Complete, Without Housing,
PCB-Only |
|
| ChipSense package | QFN | |
| ChipSense product on-board | 2.1-16 | |
| Wavelength range configuration options | VIS/NIR/NIR-BP/SWIR/
Full Range |
|
| Wavelength range configuration VIS | nm | 550 – 950 |
| Wavelength range configuration NIR | nm | 850 – 1700 |
| Wavelength range configuration NIR-BP | nm | 850-1100 |
| Wavelength range configuration SWIR | nm | 1100 – 1700 |
| Wavelength range configuration Full Range | nm | 550 – 1700 |
| Light Source Type | Tungsten-based filament | |
| Light Source power consumption (full. Power) | W | 0.5 |
| Light Source dimmable | Yes, 64 levels | |
| Light Source lifetime | h | 40.000 |
| Light Source Operation Mode | Continuous/Triggered | |
| Signal acquisition method | Sequential | |
| Acquisition Time per Channel Range | ms | 7.5-140 |
| Signal to Noise ratio (White ref. sample) | dB | 70 |
| Optical window dimension | mm | 10×10 |
| Measurement area | mm | 5×4 |
| Max working distance | mm | 2 |
| Device Control via PC SW (SpectraWeb) | Yes | |
| Device Control via PC SW (SpectraByte) | Yes | |
| On-Device User Interface | none | |
| Wired Connectivity | USB-C | |
| USB-C Protocol | USB serial port (115.2 kbps) | |
| 6 pole SH protocol | UART or RS485 (115.2 kbps) | |
| Wireless Connectivity | Wi-Fi (2.4 GHz) | |
| Power supply | DC (USB) or Battery | |
| Voltage Supply | V | 3.7 – 5.1 |
| Current Consumption Stand-by | mA | 110 |
| Current Consumption Light Source on at Max
Power |
mA | 290 |
| Size (l x w x h) | mm | 52 x 34 x 32 |
| Size (only PCB) | mm | 46.42 x 26.55 x 1.7 |
| Recommended Operating Temperature | °C | 10 – 40 |
| Operating temperature | °C | 0 – 50 |
| Accessories delivered in package | USB-C Cable, White
Reference |
|
| Software companion | SpectraByte, SpectraWeb,
FW update tool |
|
